Promax PROWATCH Neo + Manual page 240

Screen Description (FM Detection type) (1/2)
►
1 Selected function (Monitoring).
2 Monitoring selection. In "Monitoring Type" select Mask Monitoring. In
"Monitorings" box select monitoring to start (it must be a monitoring
previously created in order to show here). Below there is a box with the
monitoring description.
3 Reference spectrum, thresholds (red horizontal lines) and detected stations
(black dots).
4 Start / Stop monitoring.
5 The "Delete" button deletes the selected monitoring and the button "New"
creates a new monitoring.
6 It shows a list of e-mails. When an alarm is triggered, a notification is send
to each one of these e-mails. It allows you to add e-mails in the box "add a
new email". To remove it press on the cross next to the e-mail. Parameters
to set the e-mail server are in the equipment's "Preferences" menu, "SMTP"
option.
Chapter 10: WEBCONTROL
Figure 141. Monitoring Creation / Edition
232 March 2025
