► Screen description
1 FM multiplex level measurement at the cursor position, along with the maxi-
mum and minimum levels detected within the time range displayed on the
screen.
2 Graph of the evolution of the FM multiplex level (dBr) over time..
3 Time span selected by the user.
► Measurements
•Freq: Tuned frequency.
•MPX: FM Multiplex level (dBr = dB relative to reference level).
•Dev: Deviation for the multiplex (with all the subcarriers).
•Max Dev: Maximum deviation for the multiplex.
Cursor Functions:

•Right/left: It moves the cursor along the graph.
Function keys:

•F1 Tuning: Tuning options.
•F3 Tools: Tools available for FM.
•F4 Advanced: Advanced Menu.
Advanced Menu

•Re-start analysis.
•Span: Time span displayed on the screen (available values: 1 min, 3 min,
10 min, 30 min, 1 h, 3 h).
Annex iii: ADVANCED FM OPTION+ BASIC DAB
Figure 176.
:
