12 SPECIFICATIONS
12.1 General
► Inputs and Outputs
Parameter
RF Input
Input Connector
Maximum Signal
Maximum Input Voltage
Analogue Video Input
Input Connector
Sensibility
Analogue Audio Input
Input Connector
Digital Video / Audio Output
Output Connector
Interfaz TS-ASI I/O (PROWATCH
Connector
USB Interface 2.0
Connector
Features
IP Interface (IPTV) (PROWATCH
Connector
Protocol
IP Interface (control IP)
Connector
Type
*. This specifications are for models PROWATCH
specific model then its name appears intro brackets.
Chapter 12: SPECIFICATIONS PROWATCH Neo +/2
PROWATCH
Value
F male
130 dBμV
50 V rms
140 dBμV
Multipole Jack
1 Vpp
Multipole Jack
HDMI™
Neo 2)
BNC Female
USB type A
Mass Storage Host
USB CDC
Neo 2)
RJ45
UDP / RTP
RJ45
Ethernet 10 / 100 Mbps
+ and PROWATCH
Neo
258
*
Neo +/2
Additional Data
75 Ω
DC a 100 Hz
Protected up to 30 seconds
Zin=75 Ω
75 Ω; positive video
Zin=10k; same V/A input multipole
jack
1080p Resolution
75 Ω
Can read and write on a pendrive USB
CDC
CDC: Communication device class
Labeled IPTV
Labeled IP CTRL
Ethernet connection is designed to
work through a switch. We do not
guarantee direct connection through a
cable.
2. When a specification is for one
Neo
