4 Select the polarization (horizontal/vertical) and the satellite band (high/low).
5 If necessary, enable the Supply output and select the supply voltage for the
LNB.
NOTE: When tuning by channel is selected, polarization, satellite band and
supply output cannot be changed, because these parameters are
determined by the channel plan.
6 In the option SCD/EN50494, select ON to enable it. It appears the
at the top right corner.
7 Also in the SCD/EN50494 option, select Configuration to access SCD/
EN50494 parameters.
The configuration window shows the options that user can modify: number of
slots, slot selected, device address, pilot signal activation (when activating the
SatCR device located in the headend, it emits a pilot signal with constant level
for each downlink frequency to identificate available channels), selected satellite
and frequency step. For each type of slot number unit there is a list of
independent frequencies to select. The user may have separate frequencies for
2, 4 or 8 slots units and these values are not lost when switching from one type
to another.
March 2025
Figura 148.
251 Chapter 11: CONNECTING TO EXTERNAL DEVICES
