Screen Description
1
Selected installation; date and time.
2
Elapsed time with filter enabled (ON).
3
Measurement with LTE filter enabled:
MER: Maximum and minimum MER for the TV channel tuned (the one
probably affected by the LTE interference signal).
LTE Power:Maximum and minimum power for the complete band, between
minimum and maximum filter frequencies.
4
Spectrum band, frequencies between minimum and maximum filter
frequencies.
5
Identifier icon of the LTE filter ON (only when using internal LTE filter).
6
Selected band; battery level.
7
Time elapsed with filter disabled (OFF).
8
Measurement with LTE filter disabled:
MER: Maximum and minimum MER for the TV channel tuned (the one
probably affected by the LTE interference signal).
LTE Power: Maximum and minimum power for the complete band,
frequencies between minimum and maximum filter frequencies.
9
Measurement units/centre frequency/span (span: 10 MHz/division).
10
Signal status (searching/locked/multiplex name).
March 2025
Figure 63.
93
Chapter 5: TOOLS
