Promax PROWATCH Neo + Manual page 166

The "Log" tab shows the alarm log data.
The "Description" tab shows a description of the alarm.
The "Settings" tab shows the following settings options:
Enable this alarm: When this box is checked the alarm is enabled.

Notify on error: It enables or disables the alarm warnings. If it is

enabled it will notify the alarm status on screen.
Log Size: It allows the user to select the number of events stored (10, 25

or 50).
Order of events: Select the order for keeping the events between

keeping the first or the last ones.
To export the alarm log connect an USB memory to the equipment and press
: Export. Data is exported into a plain text file.
5.17.6 PID List
Description
►
This tool shows an ordered PID list with a short explanation of each PID and its
bitrate. Bitrate is refreshed continuously to help in understand bandwidth usage.
Chapter 5: TOOLS
Figure 104.
158 March 2025
