in which signals of different type and origin interfere with each other, as may
occur during the transition from analogue to digital TV.
5.5.2
Operation
The MER by carrier tool is available for signals with carriers: DVB-T, DVB-T2
and DVB-C2.
1
Connect the RF input signal to the equipment.
2
Select terrestrial band and tune a DVB-T, DVB-T2 or DVB-C2 digital signal.
3
Press the Tools key
4
Select MER by carrier option.
5
The MER function appears on screen.
6
To exit press any key of mode (TV mode, Spectrum mode or Measurement
mode).
Screen Description
►
1
Selected installation; date and time.
2
Cursor active mode; Selected band, battery level.
March 2025
MER by carrier
.
97
S
C
A
N
Chapter 5: TOOLS
