7 Press the Spectrum
again this key to switch among views. Select the SPECTRUM 1/3 view.
8 Press Enter to change to SP mode. In this mode, when moving left or right
it changes the Span. The recommended value for a satellite signal is 100
MHz. The span value is shown at lower right corner. Once is selected, press
again the Enter to return to Tune mode.
9 Press the up or down to adjust the reference level.
10 Press the
frequency or by channel.
11 If you select the option tune by frequency, press the Settings
select the settings parameters: Supply voltage, polarization and satellite
band.
12 If you select the tune by channel option, then select in "Channel plan" a
proper channel plan according to your area. Channels from channel plan
have pre-set parameters (supply voltage, polarization and satellite band),
so they cannot be changed from the Settings menu.
13 In case you do not find a proper channel plan, you can add or create a new
channel plan using one of this tools:
•Press
•F3: Tools -> Explore Channel Plan.
•WebControl -> Installations management -> Create a Channel Plan.
14 Press
15 Search your frequency or channel by moving the cursor left or right. You can
also enter a frequency or select a channel on menu
16 If the signal is locked, then some info about the signal shows up on the lower
left corner. A triple cursor shows the bandwidth for the signal detected in
case it is a digital carrier.
17 The meter detects automatically all the parameters for the signal and shows
on screen the main measurements.
Chapter 2: SETTING UP
key. The signal spectrum appears on screen. Press
key and in the "Tune by" option select if you want to tune by
-> : Manage -> F3: Installation -> Add Channel Plan.
and confirm StealthID is enabled (On).
Standard operation
How to point a rotor driven antenna
40
key and
.
S
C
A
N
S
C
A
N
