Screen Description
►
1 Selected installation; date and time.
2 Measurement values for the signal tuned at the frequency/channel selected.
3 Spectrum over time at the selected span.
4 Softkeys menus.
5 Selected band, battery level.
6 Maximum and minimum values of signal power and band power over time.
7 Maximum and minimum value of the measure selected by the user in the
option "User measure" (see next section).
8 Elapsed time.
9 Signal status (searching / locked / multiplex name / selected span).
Cursor functions:
•No function for this tool.
Axis description:
•Axis X: Span (MHz).
•Axis Y: Power.
5.7.3 Menu Options
At the bottom of the screen there are four menus available via the function keys.
Chapter 5: TOOLS
Figure 66.
