7 Press the Enter to change to SP mode. In this mode, when moving left or
right it changes the Span. The recommended value for a terrestrial signal is
50 MHz. The span value is shown at lower right corner. Once is selected,
press again Enter to return to Tune mode.
8 Press the joystick up or down to adjust the reference level.
9 Press the
frequency or by channel.
10 If you want to tune by channel, then select a proper channel plan according
to your area in option "Channel plan".
11 In case you do not find a proper channel plan, you can add or create a new
channel plan using one of this tools:
•Press
•F3: Tools -> Explore Channel Plan.
•WebControl -> Installations management -> Create a Channel Plan.
12 Press
13 Search your frequency or channel by moving the cursor left or right. You can
also enter a frequency or select a channel on menu
14 If the signal is locked, then some info about the signal shows up on the lower
left corner. A triple cursor shows the bandwidth for the signal detected in
case it is a digital carrier.
15 The meter detects automatically all the parameters for the signal and shows
on screen the main measurements.
2.9.2 RF Satellite signal tuning
1 Connect the RF input signal cable to the RF input connector of your
equipment.
2 Press the Preferences
3 Access the tab "Stealth ID" to use the automatic identification feature.
4 Select the type of signals you want to identify when the meter is searching
a signal. Press "Save" and "Exit".
5 Press the Settings
Satellite.
6 If you want to use a rotor to move the satellite dish, press the Settings
key and enable the option "Supply output". Then select the communication
protocol you are going to use to send commands to the rotor (DiSEqC, SCD,
SCD2).
March 2025
key and in the "Tune by" option select if you want to tune by
-> : Manage -> F3: Installation -> Add Channel Plan.
and confirm StealthID is enabled (On).
key for 1 second.
key. At "Source of signal" select RF. At "Band" select
39
.
Chapter 2: SETTING UP
