Data fields to be filled are:
Antenna:
►
Type: In this box the user must select the type of antenna between

manual and any other type of antenna available. If you select the manual
antenna, you must enter the correction factor by hand. If you select an
antenna type then the correction factors associated with each frequency
are applied. These data are defined in the antenna file imported by the
user (refer to next section to know how import antenna data).
Factor: This is the correction factor (K) for the antenna at the

measurement frequency.
Detector Type: (PEAK/RMS). It allows the user to select between

maximum PEAK detector or RMS detector. The maximum peak detector is
mainly used for analogue modulated signals, while the RMS option is the
right choice for digital modulated signals.
Cable
►
Type: In this box the user must select the type of antenna between

manual and any other type of cable available. If you select the manual
cable, you must enter cable loss by hand.
Loss (dB): In this box the user must enter the estimated loss for the cable

used to connect to the antenna.
At the bottom of the configuration window you can see the field strength in real
time according to the current frequency and correction factors.
5.15.4 Creating and Importing Calibration Tables
The user can import the antenna calibration data obtained from the
manufacturer. There is a template (available on the download area at PROMAX
March 2025
Figure 94.
