4.6.4
4K Decoding
PROWATCH
*. Available for
The equipment has the "4K Frame Grabber" function. This function decodes UHD
video frames and displays them on screen as a slideshow.
The equipment can identify the HEVC (H.265) signalling and display its
transmission data such as the video type, profile format, aspect ratio, bit rate
and image.
4.6.5 LTE Signals
The equipment can measure LTE signals at 900 MHz (band 8) or at 2600 GHz
*
(band 7) .
1 Connect the RF input signal to the equipment. In "Settings"
source signal and the terrestrial band.
2 Select the Spectrum Analyzer mode
signal.
3 In this kind of signal the user can select its bandwidth from "Signal
Parameters" on key
4 Now press F1 and select tuning by channel or frequency. If you have a
channel plan with the operators channels
If not then use tuning by frequency.
5 If using tuning by frequency, enter the frequency for the operator's link you
want to measure. If using tuning by channel just select a channel.
*. Band 7 is an expansion option. Refer to annex.
**.Contact PROMAX for specific LTE channel plans.
March 2025
*
Neo
2
Decoding a real 4K signal in DVB-T2
. Usually the bandwidth for this signal is 10 MHz.
. Press
**
then use the tuning by channel.
85
select the RF
and select the GENERIC
Chapter 4: RF SIGNAL TUNING
