► Operation
1 In "Monitoring type" box select "Signal Quality Monitoring".
2 In "Monitoring" dropdown menu, select an existing monitoring or create a
new one by clicking "New". You can also import a monitoring (in zip format)
by pressing "Import" (this monitoring previously must be created and
exported using the "Export" option).
3 If you create a new monitoring, a box will appear that allows you to select
the channel plan that you want to monitor. In case the system detects a
monitoring that was not finished, then it allows you to load it in order to finish
it.
4 Next, the "Name" box appears. Write a name to identify the monitoring. In
the "Description" box add additional information.
5 A list will appear with all channels in the channel plan. Alarms on each
channel are available to be set.
6 To set an alarm from a channel, click on the cross icon next to channel. It
drops down a list with all parameters available.
7 Each channel can be configured with this parameters:
Auto:

measurements and reports an alarm when the user-defined condition is
met.
Manual: The system tunes the channel and waits during a time defined by

user (in seconds). Then it takes measurements and reports an alarm
when the user-defined condition is met.
Cycles: The system reports an alarm when the user-defined condition is

met during a number of consecutive cycles defined by user. If this box is
empty is equal to 1 cycle.
8 When the channel is deployed, the alarm configuration will appear:
Status unlocked: This condition is always enabled and reports alarm when

the channel is unlocked.
Parameter: Parameter to monitor.

OVER / UNDER: It indicates the condition to met in relation to the user-

defined value.
Pre-alarm: Press on the switch and enter the value so when the condition

is met it reports a pre-alarm. Value must be in decimal notation.
Alarm: Press on the switch and enter the value so when the condition is

met it reports a pre-alarm. Value must be in decimal notation.
9 Configure each channel to be monitored.
