Parameter
Optical to RF Converter
Dynamic range of conversion
RF Attenuation
RF band converted (Optical Cable
and DTT links)
RF band converted (Optical IF-
Satellite Installations)
RF Output
6 GHz RF Auxiliary Input
Connector
Frequency Bands
Dynamic Range
Span (min-max)
Conversion Gain
Flatness
Spurious
Inter-modulation Products
Maximum Input Signal
► WiFi 5G Analyzer + LTE 2.6 GHz
Parameter
Descriptive Code (for
Neo
PROWATCH +)
Descriptive Code (for
Neo
PROWATCH 2)
TBD
► DAB / DAB+ Advanced (PROWATCH
Parameter
Descriptive Code (for
Neo
PROWATCH 2)
Modulation
Combined Antenna Input
DAB Sensitivity
Decoding Audio Service
Transmission Mode
Chapter 12: SPECIFICATIONS PROWATCH Neo +/2
Value
-5 dBm - +10 dBm
ON = 15 dB; OFF = 0 dB
65 MHz - 1000 MHz
950 MHz - 5450 MHz
65 MHz - 2150 MHz
SMA
Sub-Band 1: 2150 MHz - 3000 MHz
Sub-Band 2: 3400 MHz - 4400 MHz
Sub-Band 3: 4400 MHz - 6000 MHz
45 -105 dBμV
60 - 120 dBμV
1 MHz - 250 MHz
2 MHz - 450 MHz
10 MHz - 1600 MHz
7 dB
-8 dB
±5 dB
< 45 dBμV
<15 dB
RF: 120 dBμV; DC: 50 V
Value
OP-001-WL
OP-002-WL
TBD
Neo 2)
Value
OP-002-DAB2
COFDM
for Band III
up to 22 dBμV
up to 384 kbit/s
I
270
Additional Data
for universal optical LNB
ATT OFF
ATT ON
for RBW = 10 kHz
for RBW = 20 / 30 / 40 kHz
for RBW = 100 / 200 / 1000 kHz (the
maximum span might be smaller
depending on the sub-band selected
by the user. This value corresponds to
the sub-band 3)
(-65 dBm); typical value
typical value
Additional Data
It includes an RF 6 GHz aux. input
It includes an RF 6 GHz aux. input
TBD
Additional Data
Typical Value
