Installations / Preferences key

•Short Press (<1s): It shows the list of installations and the menus to
manage them.
•Long Press (>1s): It shows the Preferences menu.
Tune Settings / Video - Audio Settings

•Short Press (<1s): It shows the Settings menu (menu changes according
to signal source selected).
•Long Press (>1s): It shows the Video & audio settings.
Screenshot / Reference key
►
Depending on how long you press this key, it has two different functions:
•Short Press (<1s): Pressing this key for less than one second on the
Spectrum Analyzer mode, it holds on screen the current waveform as a
trace or reference. It is equivalent to go to the option "Reference - Set"
from the "Advanced" menu. Pressing short again, it deletes the waveform
reference. It is equivalent to go to the option "Reference - Clear" in the
"Advanced" menu.
•Long Press (>1s): Pressing this key for one second it makes a capture of
what it is shown on screen at the time. The capture may be from the
screen image, from the measurement data or from both. The type of
capture, either screen, data, or both can be set in the "Export button"
option which is on the label "Measures" in the "Preferences" menu (for
more details refer to
page 134).
Mode keys
►
On the left side there are three keys to access the most important modes of the
meter.
Measurement key (key M).

Spectrum Analyzer key (key S).

TV Mode key (key T).

Pressing on one of these keys repeatedly provides access to a different view
within the same function. For analogue signals only the first view of each
Chapter 2: SETTING UP
(Key F)
(Key P)
"Screen and Data Capture (Export key)" on
26
(Key C)
