3
Selected band; battery level.
4
Exploring the spectrum in real time.
5
Level/Power, C/N ratio, MER, time remaining to identify a channel, elapsed
time since the start of the channel identification.
6
Softkey menus.
7
Current channel plan, progress bar in the current channel plan, selected test
point.
8
Channel, frequency and Downlink.
Screen Description (Data Viewer)
►
March 2025
Figure 87. Channel Plan Data Viewer.
131
Chapter 5: TOOLS
