the echo on the main path (the stronger signal).The vertical axis represents
the attenuation of the echo in dB on the main path.
5 Data box with main data regarding echoes. EIn the list of echoes it shows the
power, the delay in microseconds and the distance in kilometres to the
echoes.
6 Signal status (searching/locked/multiplex name).
7 Softkeys menus.
Cursor functions:

•Cursor left/right (Channel/Frequency mode): It changes the channel/
frequency (according to the tuning type selected).
•Cursor left/right (Echoes mode): It changes echo.
•Cursor up/down (Echoes mode): It changes zoom.
Remember to press the Enter to switch between the Echoes (EC) mode and the
Channel/Frequency (CH/FR) mode.
5.4.3 Menu Options
At the bottom of the screen there are four menus available via the function keys.

allows the user to select a channel or frequency, a channel plan and
access the tuning menu.

the signal parameters.


on the echoes windows. Zooms are 1x, 2x, 4x and 8x.
5.5 MER by Carrier
5.5.1 Description
The MER by Carrier function analyses continuously the measure of the MER value
for each one of the carriers forming the selected channel and they are displayed
in a graphic on screen. This tool is especially useful for the analysis of systems
Chapter 5: TOOLS
It displays the channel/frequency where is pointing the cursor, it
It displays the selected transmission standard menu and accesses
It displays the Tools menu.
It displays the Advanced menu. The ZOOM option changes the zoom
