Promax PROWATCH Neo + Manual page 178

Settings
►
1 Press "Installation management" key (F key) for one second to access the
"Preferences" settings.
2 Go to "Streaming V/A" tab and set streaming parameters:
IP Address: It is the IP address of the computer where we are going to

broadcast in streaming from the meter.
Port: Computer broadcasting IP port.

3 Once done, press
Operation
►
1 Tune channel and service to broadcast in streaming.
2 Connect the Ethernet cable to meter using the IP CTRL port.
3 Press key
4 Select Streaming V/A option. There are these options:
•Start TS: It starts streaming the complete Transport Stream (all services).
•Start Current Service: It starts streaming the selected service.
•Stop: It stops streaming.
5 The icon
6 To watch streaming service from a computer you need a software that can
play this type of service, such as VLC multimedia player (free software).
7 In VLC, open "Media" from tool bar and select "Open Network Stream".
8 In the box "Enter a network URL" enter this text udp://@:1234 and press
on "Play". "1234" is the port in the computer (see settings section). If
everything is right, it will play the service on the computer screen.
9 If you are streaming the whole TS, open "Playback" from toolbar and select
"Program". It will show all available TS services. Select the service to watch
on screen.
10 To exit streaming, press
Chapter 5: TOOLS
to save changes and
: Tools.
at the top right corner means streaming is working.
: Tools, select "Streaming V/A" and then "Stop".
170
to quit "Preferences".
March 2025
