Promax PROWATCH Neo + Manual page 35

function is available. Each view name is shown at the top centre of the screen.
When reaching the third view it returns to the first view.
2.5.4 Function keys or Softkeys
There are four programmable keys, also called softkeys, numbered from
for the portable meter that are equal to keys F1, F2, F3 and F4 from the
keyboard.
Each key provides access to one menu. This menu changes according to the
mode or tool selected.
The menu is displayed over each softkey at the bottom of the screen.
2.5.5 Select and Edit Parameters
To edit or select any parameters follow these instructions:
1 Place over the option and press the Enter.
2 The data field gets into the edit mode (yellow background).
3 A menu is deployed with some options or if it is numeric, a number gets a
black background.
4 Move the up/down to select one option. To move between figures press
right/left and to change it press up/down.
5 After finish press Enter to confirm or any function key to exit.
2.5.6 Text Edition
When a user needs to enter or edit a text (from an image, Channel Plan, etc.),
a screen with a virtual keyboard appears (see figure).
March 2025
Figure 28.
27
to
Chapter 2: SETTING UP
