TER. Downlink: If this option is enabled it allows you to set a local

oscillator in terrestrial band from Settings
and downlink (DL) frequencies calculated from local oscillator. For
example, it allows you to work with terrestrial radio-links or frequency
converters.
Position Tone: The user can select where at the voltage to insert a 22 kHz

tone: Up, Center or Down. The tone will be inserted on the top, in the
center or below the LNB tension respectively.
Min. TER. Power: It sets the minimum power for a terrestrial digital signal

to be identified when channel exploring or datalogger.
Min. SAT. Power: It sets the minimum power for a satellite digital signal to

be identified when channel exploring or datalogger.
Min. TER. Level: It sets the minimum level for a terrestrial analogue signal

to be identified when channel exploring or datalogger.
Min. FM Level: It sets the minimum power for a FM signal to be identified

when channel exploring or datalogger.
Input Impedance: It allows the user to select the impedance at the RF

input between 50 Ω and 75 Ω.
Power Offset: It adds this value to the power/level measurement. When

this value is different to 0 dB, next to power/level measurement an
asterisk (*) is shown as a warning that offset is been applied.
Tools Options
►
Datalogger PSI: If you select the option "Capture", when datalogger is

working it captures the service list of each channel. This process slows the
datalogger, but provides additional information that can be downloaded in
XML files. To disable this option select "Don't capture".
Database Services: When it is enabled, it saves all the services been

detected in the current installation. There is a database for services in
terrestrial band and another for services in satellite band. Services are
included automatically when the signal is locked. If enabled, these
services will be displayed on the "View all services" option in the Tuning
menu.
Export Button: It allows the user to select the data to be exported when

pressing the export key among the following options: screen only, data
only or both. More info in the "Export key" chapter.
LTE Filter F. Min: Select the minimum frequency for the external LTE filter.

LTE Filter F. Max: Select the maximum frequency for the external LTE

filter.
Center Frequency: User can set the center of frequency to Manual or

Auto mode. In Manual mode the user sets the center of frequency and
the equipment does not change it never, so the main cursor can be moved
March 2025
and it displays intermediate
