Channel Plan
►
This option allows the user to select a channel plan from the ones available for
the current installation.
Tune by
►
It allows the user to select between tuning by channel (selecting a channel or
channel by channel with the cursor) and tuning by frequency (selecting a
frequency or step by step with the cursor).
In case of tuning by channel:
1 Place over the Channel option and press Enter.
2 A box appears with all channels of the active channel plan and its frequency.
3 Move along the box to select a channel.
4 After finished press Enter to save the selected value or any function key to
exit without saving.
5 The cursor will place on the selected channel and it will appear on the
option.
•Channels can be changed directly with the cursor in CH mode.
NOTE: When using tune by channel on satellite, the polarity parameters
(horizontal/vertical and left/right) and satellite band (high/low) are
selected automatically by the equipment, according to the channel plan
enabled and cannot be changed by the user. To change these
parameters, the user may switch to frequency tuning. But the user can
change the voltage output while in a channel plan, as long as none has
been defined in that same channel plan. For instance, if a standard
channel plan is being used like the CCIR, there is no need for switching
to frequency tuning mode.
In case of tuning by frequency:
1 Place over the Frequency option and press the cursor.
2 The option is highlighted in yellow to indicate it is in edit mode.
3 Move left/right to move between the figures and up/down to change the
figure.
