10.9.3
Channel Plan Editor
This function allows you to edit channel plans.
Channel Plan Editor Operation
►
1
Files with channel plans are inside the "CH" folder. "SAT" sub-folder contains
satellite channel plans, "TERR" sub-folder contains terrestrial channel plans
and "AUX" contains other channel plans. Select the file that contains the
channel plan to edit and press the right button on the mouse to select the
"Edit channel plan" option.
2
The channel plan definition parameters and all the channels that form it will
appear. From here you can edit any value by clicking on the box.
3
Channels can be modified by clicking on each parameter or deleted by
pressing the red cross.
4
Once the channel plan is finished, click on "Download Channel Plan" to
download it to the PC. By default the file with the channel plan is downloaded
in the PC "Download" folder. The file is in XML format.
5
To use the channel plan on the equipment use the File Manager to upload the
XML file. It must be uploaded to the installation's CH folder and within the
sub-folder TER, SAT or AUX depending on whether it is terrestrial, satellite
Chapter 10: WEBCONTROL
Figure 138. Channel Creation
224
March 2025
