11.8.1 TS-ASI Input
The TS-ASI option is a key feature. You can monitor and analyze streams coming
from satellite receivers, transport stream players, multiplexers, etc... It
automatically detects whether the stream is composed of 188 or 204 bytes.
Operation
►
1 Press the Settings key
2 Select the Decoder TS Input option. It shows up a menu to select the
transport stream coming into the equipment between the RF Demodulators,
IPTV and the ASI Input.
3 The RF Demodulators option (this option is available only if RF is selected
as a Signal Source) extracts the TS from the RF signal by means of the
internal RF demodulator. The RF signal can come from digital terrestrial,
satellite or cable.
4 The IPTV option (this option is available only if IPTV is selected as a Signal
Source) extracts the TS from the IPTV signal.
5 The ASI Input option gets the TS directly through the ASI-TS input
connector.
11.8.2 TS-ASI Output
It can transmit in packet mode or burst mode. User can use the transport stream
received by the equipment to feed the signal to other devices as well through
the TS-ASI output.
Operation
►
1 Press the Settings key
2 Select the ASI Output option. It allows the user to select the signal source
for the TS-ASI packets going out through the ASI Output. User can select
among Off, IPTV, RF demodulators and ASI Input. By this way, the transport
stream can feed another device.
3 The Off disables the ASI Output. If the RF Demodulators option (this
option is available only if RF is selected as a Signal Source) is selected, the
signal through ASI Output is the TS extracted from the RF signal by means
of the internal RF demodulator. The RF signal can come from digital
terrestrial, satellite or cable. If the IPTV option is selected (This option is
available only if IPTV is selected as a Signal Source), the signal through ASI
Chapter 11: CONNECTING TO EXTERNAL DEVICES
(key C) to access the settings.
(key C) to access settings.
256 March 2025
