4 Boxes to select parameters for historical data query:
•Monitoring Type: Select "Signal Quality Monitoring".
•Monitoring: Select monitoring to obtain data.
•Channel or all channels.
•Measurement type or all measurements.
•Date and time (from / to). The query can be up to 7 days. You must put
date and hour at the location where the meter is monitoring (not the date
and time from where you are making the query, unless both were in the
same time zone).
5 Data table / graph (graphic bar is only displayed when one single channel and
one measurement type is selected). Click on the corresponding label to
switch between Table and Graph. Alarms table shows when the alarm or pre-
alarm was reported and when disappeared. If signal is unlocked some
measurements related to demodulation (MER, CBER...) will be empty.
Measurement data keep units used when monitoring.
10.9 Installations Management
Description
►
Installations Management allows you to access the File Manager and the Create
Channel Plan tool.
To access this screen, click on the Installations Management icon
10.9.1 File Manager
This function allows you to manage files inside an installation (channel plans,
screenshots, dataloggers, etc.).
File Manager Operation
►
1 Press on tab "File Manager" to access the file manager. Wait for few seconds
to system to read all files from the equipment.
2 All installations are shown on the left side of the window. Each folder is for
an installation. When clicking on a folder it deploys its content in a tree
structure. The area on the right side shows the content inside the selected
folder.
