1 Selected installation; date and time.
2 Spectrum.
3 Power measurement over time (window size is span time set in
configuration).
4 MER and C/N measurement over time (window size is span time set in
configuration). In case of monitoring a FM signal, it shows nothing as there
is no measure to draw.
5 Indicator of signal monitoring started.
6 LNB, Selected band; battery level.
7 Signal information window 1:
Frecuency: frequency at which signal is locked; Profile (only for

DVB-T2 signals): Base or Lite; PLP identifier (only for DVB-T2 signals):
identifier of the layer being measured, TS Hierarchy (table hierarchy at
the transport stream) TS Priority (packet priority at the transport
stream).
8 Signal information window 2:
Measurements of the signal over time.

9 Signal information window 3:
File name: Name of the current monitoring.

Elapsed: Time elapsed since the beginning of the monitoring.

Samples: Samples taken since the beginning of the monitoring.

Space left: Space left in the memory to save data.

10 Channels from the channel plan being monitored. Measurement data are
from the selected channel (pointed by a red arrowhead).
March 2025
Figure 69. Channel Plan Monitoring
