key") and after that display the images or download the data files (in XML
format).
NOTE: In both satellite and terrestrial band, the system saves the LNB state
every time the user sets a reference and uses this value always that the
equipment is working in this mode.
Screen Description
►
1 Installation selected, date and time.
2 Selected band; battery level.
3 Status message depending on the attenuation level.
4 Power level of the signal.
5 Signal Frequency (MHz).
6 Power level of the reference signal obtained when setting the reference and
used to calculate the attenuation level (dBµV).
7 Power level of the test signal at the user access point (dBµV).
8 Attenuation level (dB); Attenuation = Reference - Current.
9 Softkeys.
Cursor functions:

•No function for this tool.
Axis description:

•Axis X: Pilot signals.
•Axis Y: Power.
March 2025
Figure 67.
105 Chapter 5: TOOLS
