The maximum level reached appears as a vertical red line and the minimum level
as a vertical blue line. The selected parameter appears with a yellow
background. Numerical values for level, maximum and minimum are below the
bars.
The other measurements have been already explained on screen Measurement
1/4.
Cursor functions:

•Up/down: Change of selected parameter.
Function keys:

•F1 Tune: Tune options.
•F2 FM: FM signal parameters.
•F3 Tools: Tools enabled for FM.
•F4 Advanced (Reset Bars): It resets bar graph measurements.
Status bar: It shows if the FM signal is locked or unlocked. If it is locked it

will show the PI (Program Identification) and the PS (Service Program).
iii.3 Tools
Press the
are disabled.
The Advanced FM option has some exclusive tools for FM:
FM MPX Spectrum.

MPX FM measurements over time.

FM Histogram.

All the other tools are explained in "Tools" chapter
iii.3.1 FM MPX Spectrum
The FM MPX Spectrum tool shows the FM multiplex spectrum in a frequency span
of 100 kHz. It shows all the subcarriers that form the FM multiplex. It gives a
general view of the FM multiplex and can help to detect problems.
Annex iii: ADVANCED FM OPTION+ BASIC DAB
key to access the Tools menu. Tools not compatible with FM signals
("TOOLS" on page
304
87).
