If "Test & Go" is performed when using the "Attenuation test" tool, then the
datalogger created will be specific to save attenuation test data.
5.12 Screen and Data Capture (Export key)
5.12.1 Description
The Screen and Data Capture function captures what is displaying on screen at
the moment. The capture can be an image, measurement data or both. This is
set through the Preferences menu ("Export button" option).
Data capture is saved in a XML file with all data, measurements and text, that
is on screen at this time. The image is saved in a PNG file.
Captures can be displayed on the equipment or also can be downloaded and
displayed through an external software.
5.12.2 Operation
Settings
►
1 Press the "Management Installation"
"Preferences" menu.
2 Go to the label " Tools" and select your option in "Export button". There
are three options available: Screen Only, Data Only or Screen+Data. "Screen
Only" saves the screen image in PNG format. "Data Only" saves
measurement data on screen in a XML file format. "Screen + Data" saves
both screen and data.
3 Once selected, press
Capture
►
1 Press the Export key
screen to be captured. The LED next to key lights.
2 A progress bar shows the progress of the capture process. When finished,
the screen is captured and the LED is OFF.
Chapter 5: TOOLS
Spectrum footprint
to save changes and
(key P) for one second when on screen appears the
134
key (key F) for one second to enter
to exit "Preferences".
