Promax PROWATCH Neo + Manual page 225

2 Monitoring selection. On Monitoring type select "Signal Quality Monitoring".
On "Monitorings" select one existing monitoring (previously, user must create
a monitoring in order to show here). Below there is a text box to add a
description to the monitoring.
3 Alarms configuration. It allows to select the Auto or Manual mode and cycles.
If you click on the cross next to the channel, the available parameters
channel will be displayed to set alarms. At the bottom there is the "Save"
button to save all changes made.
4 When pressing on "Start Monitoring" it will start monitoring.
5 The "Delete" button deletes the selected monitoring and the button "New"
creates a new monitoring.
6 It shows a list of e-mails. When an alarm is triggered, a notification is send
to these e-mails. It allows you to add e-mails in the box "add a new email".
To remove it press on the cross next to the e-mail. Parameters to set the e-
mail server are in the equipment's "Preferences" menu.
Screen Description
►
1 Parameter selected shown on graphic bar.
2 Start / Stop monitoring.
3 Graphic bar of selected parameter. At the bottom the channel being
measured. When pressing on a graphic bar channel it pops up a window with
*. In case you have DAB Advanced or FM Advanced installed, it shows advanced measurements
related to these options.
March 2025
Figure 135. Monitoring started
217
*
of the
Chapter 10: WEBCONTROL
