Promax PROWATCH Neo + Manual page 199

DHCP: Enable this option to get the proper IP address when the unit is

first connected to a network. That feature contributes to make things
easier to installers when debugging network access. Enable the DHCP
protocol for proper IP configuration.
IP Address: IP Address of the equipment into the local network.

Mask: Subnet mask of the equipment (by default 255.255.255.0).

Gateway: It allows the meter to get out from the local network when using

PING or TRACE (if the network does not have gateway, use 0.0.0.0).
IGMP Version: Protocol for multicast transmissions used by the router.

Available versions are 1, 2 and 3 (by default it is disabled - Off).
•IGMPv1: IGMP version 1. Each time user selects a multicast address,
meter asks for the new multicast stream.
•IGMPv2: IGMP version 2. Each time user selects a multicast address,
meter stops receiving the current stream and asks for receiving the new
one.
•IGMPv3: IGMP version 3. Each time user selects a multicast address,
meter stops receiving the current stream and asks for receiving the new
one, from the servers approved by the user.
•Off: Meter does not send any IGMP messages and discards the received
ones.
General Settings
►
When pressing the settings
Signal Source: It allows the user to select the signal coming into the

equipment. Select IPTV.
Decoder TS Input: It allows the user to select the transport stream coming

into the equipment among RF demodulator, IPTV input and ASI input. If
you want to save the transport stream received by the IPTV, select the
IPTV input.
ASI Output: It allows the user to select the way out for TS-ASI packets.

User can select among Off, IPTV and ASI Input. This transport stream
received by the equipment can feed the signal to other devices as well. If
you want to send to the output the transport stream from the IPTV signal,
select IPTV. In the case of IPTV option the TS-ASI packets go out through
the IPTV connector.
7.5.3 M3U file import
M3U are files that contain a list of services available on streaming. To load one
of these files on your meter follow these steps:
1 Copy your M3U file on a pendrive.
March 2025
(key C) it shows IPTV settings:
191 Chapter 7: IPTV
