Promax PROWATCH Neo + Manual page 123

In the second one, you will find the same data but presented in a table

format, more user friendly for working with graphs based on each
measured parameter.
8 Now save the data as a true excel file. No specific name or path is required,
but you must remember the path.
5.10 Signal Coverage
5.10.1 Description
The Signal Coverage function allows the user to check signal for a tuned signal
or a channel plan (several channels) by measuring power and other parameters
over time.
The position where all these measurements are taken is determined by a GPS
receiver. When the equipment locks a GPS signal, it automatically sets date and
time using the GPS signal. As long as the GPS is locked, date and time is updated
every hour.
All this data, measurements and GPS position can be downloaded to a PC and
exported to a file for later analysis.
5.10.2 Operation
The Signal Coverage tool is available for all RF signals.
1 Connect the GPS
2 In Settings menu
satellite band.
3 Access the Spectrum mode and tune the signal for coverage study.
In case of tuning a DVB-T2 signal, in the Signal Parameters menu

select the Profile (Base or Lite) and the PLP identifier. User has to choose
one profile and one PLP identifier per each signal coverage analysis .
4 Press the Tools key
*. GPS is not included for
March 2025
Signal coverage 1/2 (GPS)
*
receiver to the meter.
(key C) select the source of signal RF and terrestrial or
.
Neo
PROWATCH
115
. Contact PROMAX to get a valid GPS.
S
C
A
N
Chapter 5: TOOLS
