Properties Figure 4 Rigid Gray - 3D Systems FIGURE 4 MODULAR User Manual

Advertisement

METRIC
Description
Speed (mm/hr) - 50 µm Print Mode/
Standard Build Style
Viscosity (cps @ 25C)
Liquid Density (g/cm3)
Solid Density (g/cm3)
Tensile Strength Ultimate (MPa)
Tensile Strength @ Yield (MPa)
Tensile Modulus (MPa)
Elongation at Yield (%)
Elongation at Break (%)
Flex Strength (MPa)
Flex Modulus (MPa)
Izod Notched Impact (J/m)
Izod unnotched impact (J/m)
Tg (DMA, E")
HDT @ 66PSI (C)
HDT @ 264 PSI (C)
CTE above Tg ((μm/m)/°C)
CTE below Tg ((μm/m)/°C)
Shore D Hardness
Shore A Hardness
24 Hour water absorption (%)
Tear Strength (kN/m)

4.13 Properties Figure 4 Rigid Gray

METRIC
Color
Description
Speed (mm/hr) - 50 µm Print Mode/
Standard Build Style
3D Systems, Inc.
METHOD
N/A
Internal Method
Brookfield viscometer
Kruss K11 Force Tensiometer
ASTM D792
ASTM D638 (rigid)/D412(elastomer/
rubber)
ASTM D638
ASTM D638 (rigid)/D412 (elastomer)
ASTM D638
ASTM D638 (rigid)/D412(elastomer)
ASTM D790
ASTM D790
ASTM D256
ASTM D4812
ASTM E1640 (E"at 1°C/min)
ASTM D648
ASTM D648
ASTM E831
ASTM E831
ASTM D2240
ASTM D2240
ASTM D570
ASTM D624
METHOD
N/A
N/A
Internal Method
48
VALUE
Production-grade additive
manufacturing material with game-
changing thermoplastic-like mechanical
properties, and environmental stability
of mechanical and performance
properties over time.
Up to 62
293
1.07
1.16
63
63
2320
4.7
12
92
2290
24
614
62
70
56
188
71
79
n/a
1.16
n/a
VALUE
Gray
The balance of thermal and mechanical
properties, combined with excellent
print quality and long-term Indoor and
outdoor stability for prototyping and
production.
Up to 48
p/n 42-D116, Rev. K
