28. Reinstall the MDM front plate, sliding the plate over the
top two screws to guide it into place. Use a T20 screwdriver
to tighten the top two screws (in green, below) and reinstall
the bottom two screws (in red, below). If you did not do so
in Step 20, ensure that the red cap has been removed from
the material-delivery tube above the resin tray, and close the
upper-build-chamber door.
29. Carefully lower your new or
concave side up, as seen at the right. It should fit snugly in the
holder on the chassis.
Note: If you did not do so in Step 20, ensure
that the red cap has been removed from the
material-delivery tube above the resin tray.
30. Close the upper-build chamber door and re-tension the
resin tray by pressing the tension toggle button.
31. On the Printer touch screen, press and hold the
button to tell the unit you have finished performing
the material-changeover procedure. This will re-enable the
Printer.
32. The printer can now fill the resin tray according to the
section Fill Resin Tray From Empty
You have successfully switched materials on a Printer! If you
experience any issues with your new material, please contact
3D Systems Service.
3D Systems, Inc.
cleaned resin tray into place,
.
