6.1.1.1.5.1 Resin Tray Status
6.1.1.1.6 Printer Status
There could also be informational symbols accompanying some statuses:
Indicates a printer error that will prevent it from printing and requires immediate attention
Indicates a warning of a printer condition that will prevent it from printing, but does not need immediate attention
3D Systems, Inc.
As mentioned in the section
that card shows the current status of the resin tray. Below is a
further explanation of these statuses:
Not Present - Indicates that there is no resin tray inside the
Printer
Tensioned - Indicates that a resin tray is present and that its
membrane is under pneumatic tension
Untensioned - Indicates that a resin tray is present and that its
membrane is not under tension
A Printer may have one of the following statuses shown in the
lower-left corner of the Status Card:
Ready - This status means that the printer operator has
marked the Printer as "ready" and that all printer sensors that
might hinder printing are satisfied.
Not Ready - This status means that the printer operator did
not mark the Printer as "ready," and/or that one or more
printer sensors that might hinder printing is not satisfied.
Printing - This status means that the Printer is currently
printing.
Aborted - This status means that the most-recent print job
was aborted.
Completed - This status means that most-recent print job has
finished building.
Untensioned - This status means that the tension arms are not
engaged on the resin tray.
Disconnected - This status means that the printer cannot
connect to the Controller for some reason. Please see item
8 in the Error Message Glossary
Disabled - This status means that the printer has been
disabled via the Printer Info. Card
job in this state.
Failed - This status means that the most-recent build has
failed.
Low Air Pressure - This status means that there is a pressure
loss in the pneumatic system. Please see item 14 in the
Message Glossary for more information.
MCO In Progress - This status means that the operator is
currently performing a
70
Resin-Tray Card , the display in
for more information.
. It cannot accept a print
Material Changeover procedure
p/n 42-D116, Rev. K
Error
.
