6.1.3.1 System Controls
6.1.3.2 Network Settings
This Settings screen shows the basic IP address configurations. The breakdown of this card is below:
The following network settings are only for the Controller, and not for individual Printers. Access these settings by tapping the
Edit button on the card above.
3D Systems, Inc.
Restart - Tap this button to restart the Controller's
A
computer. This does NOT affect any of the
Printers or active print jobs.
Shutdown - Tap this button to shut down the
B
Controller's computer. This does NOT affect any
of the Printers or active print jobs.
Job Queue Assignment Toggle - Choose between
C
automatic or manual print-job assignment for
all Printers attached to this Controller. Please
see the section
information.
Controller Name - This is the name assigned to
D
this Controller. Tap the
button to change the name.
Port A - This is information about Ethernet Port A
A
on the back of your Controller.
DHCP Toggle - Quick access to turn DHCP on/off.
B
When DHCP is enabled, the network connected
to Port A must supply an IP address to the
Controller using DHCP. When DHCP is disabled,
your network administrator will be able to
manually assign an IP address to the Controller's
Port A.
Port B - This is information about Ethernet Port B
C
on the back of your Controller.
DHCP Toggle - See item B, above.
D
Edit - Tap this button to expand the card and view/
E
change more-detailed network settings.
78
Job Queue Assignment for more
