6.1.2.1 Queue Toolbar
6.1.2.2 Active Print Jobs
Jobs in this section are those that are actively printing, completed, failed, or aborted, and have not been removed from the
machine. Once a print job completes/fails/aborts, removing the print platform from the machine will move the job to the
Completed Print Jobs section. A breakdown of the Active Print Jobs section is seen below.
Active Print Jobs Button - Tap to expand/collapse the Active Print Jobs list.
A
Module - The Printer that the job is printing on.
B
Material - The material that was sent over with the build file from 3D Sprint
C
Submitted - The date and time the job was submitted to the Controller
D
Completion - The date and time the job is estimated to complete
E
Left - The estimated time left in the print job
F
3D Systems, Inc.
Add Print Job - Tap this button to add a print job
A
via USB.
Print Job Information - When a print job is
B
selected, tap this button to see more information
about the job.
Duplicate - When a print job is selected, tap this
C
button to duplicate the job.
Move to Top - Tap this button to move the
D
pending print job to the top of the queue.
Move Up One Spot - Tap this button to move the
E
pending print job up one spot in the queue.
Move Down One Spot - Tap this button to move
F
the pending print job down one spot in the queue.
Move to Bottom - Tap this button to move the
G
pending print job to the bottom of the queue.
Abort/Delete - When an active print job is
H
selected, tap this button to abort the job. This
button becomes a "Delete" icon (in the red square
in the picture) when a pending or completed print
job is selected.
75
p/n 42-D116, Rev. K
