6.1.3.5 Diagnostics Logs

6.1.4 Adjustments

Controller Touch Screen
• The Controller touch screen is able to be tilted up, down, and side-to-side. Its height can be adjusted up and down as well.
Keyboard
• The keyboard tray height can be adjusted up and down.
3D Systems, Inc.
Export Logs - Plug a USB drive into the Controller and
A
tap the button to export diagnostics log files for 3D
Systems Service.
Note: After the log-file download has
begun, do not navigate away from this
screen until it has finished downloading.
Navigating away prematurely will cause
the download to stop.
Additional Info - Tap this button to see a read-only
B
screen with more systems information.
Reset to Factory Settings - Tap this button to restore
C
everything on the Settings tab to the original, factory
state. In the resulting pop-up, you can also opt to only
clear out your print queue, rather than resetting all
user-configurable items.
81 p/n 42-D116, Rev. K
