Material Mixing/Stirring Chart
NAME
General Purpose
Figure 4 PRO-BLK 10
Figure 4 TOUGH GRY 10
Figure 4 TOUGH GRY 15
Figure 4 TOUGH-BLK 20
Figure 4 FLEX-BLK 10
Figure 4 Rigid White - Remove cartridge
each morning and mix according to
column 2
Figure 4 Rigid Gray - Remove cartridge
each morning and mix according to
column 2
Figure 4 Tough 60C White
Figure 4 Tough 65C Black
Figure 4 Tough Clear
High Temperature
Figure 4 HI TEMP 300-AMB
Figure 4 High Temp 150C FR Black
High Temperature and Medical
Figure 4 MED-AMB 10
Elastomer
Figure 4 ELAST-BLK 10
Figure 4 RUBBER-BLK 10
Figure 4 RUBBER-65A BLK
Casting
Figure 4 EGGSHELL-AMB 10
6.3.1.1 Resin Mixer
Material that is left in the resin tray between builds needs to be stirred periodically. In this case, you would use the Resin Mixer
to stir the material, as seen below. Refer to the section
long to stir the material.
CAUTION: Failure to sufficiently mix materials before each build may result in color deviation and/or print
failure.
CAUTION: Ensure that the mixer is clean before each use. To clean the mixer, wipe it with a nonabrasive cloth
and Isopropyl Alcohol (IPA) or Ethanol (EtOH).
3D Systems, Inc.
HAND MIXING TIME REQUIRED
2 mins.
n/a
No mixing time required
No mixing time required
2 mins.
No mixing time required
Premix Material Before Cartridge Installation
86
STIRRING TIME REQUIRED (IN
RESIN TRAY)
30 secs. - do not contact film
30 secs. - do not contact film
30 secs. - do not contact film
30 secs. - do not contact film
30 secs. - do not contact film
30 secs. - do not contact film
for information on how
