# ERROR TEXT ON
PRINTER DISPLAY
32 Job Aborted: Material
Leak Our Sensors have
detected a material
leak. Please consult
with the user guide.
3D Systems, Inc.
ERROR TEXT ON
CONTROLLER
Possible leak detected
in [printer name] Our
sensors have detected a
resin leak in the printer.
Current job is being
aborted and printer will
remain disabled until leak
is cleared. Please refer
to the user guide for
cleaning procedure.
179
STACK LIGHT HOW TO CLEAR
STATE
Flashing red
This message appears if there is a
material leak detected when the machine
IS printing.
1. Inspect resin tray and upper-build
chamber for leaking material.
a. If you suspect that the resin tray
is leaking, perform the steps in
the section
Leak
b. If overflow is observed, turn off
the printer. Refer to troubleshooting
item HW4
Cease operation of the printer and
contact 3D Systems Service.
2. Remove the MDM front panel and
inspect both the
MDM Drip Tray
a. Inspect MCO tubing, inside of MDM,
upper build chamber and cartridge
for cause of leak.
b. If MCO tubing is found to have
a leak, perform the procedure
Remove/Replace MCO Tubing Only
c. If cartridge is found to have a leak,
remove and replace it according
to
section.
d. Clean both drip trays, and spill
sensor, according to the section
Clean Drip Trays
3. If there is little, or no, material in
either drip tray: inspect the Spill Sensor.
Ensure it is properly seated in its
mounting bracket. If it is not seated
properly, the system will think there is
a material leak.
Spill sensor fully seated
4. Tap Overflow Resolved on the Controller
popup:
5. Complete the steps in the section
Aborting
Recover from Resin-Tray
.
to clean the material spill.
Printer Drip Tray
for material.
HW20 in the Troubleshooting
.
.
p/n 42-D116, Rev. K
