# ERROR TEXT ON
PRINTER DISPLAY
17 Empty cartridge Please
insert new cartridge.
18
Printing [job name]
*progress bar,
percentage*
Button: Abort
19 Replace Cartridge
Within 3 Mins
Insufficient Material to
complete job.
20 Paused: [JobName]
Machine will resume
printing when material
levels rise. The job will
abort in X:XX minutes...
21 No material cartridge
present Please replace
material cartridge to
keep printing.
22
Printing: [Job Name]
There is no material
cartridge present.
Please replace material
cartridge to print next
job.
Button: Dismiss
3D Systems, Inc.
ERROR TEXT ON
CONTROLLER
Replace material cartridge
on [printer name] The
material cartridge on
[printer name] is empty.
Please insert new material
cartridge to print next job.
Empty material cartridge
on [printer name] Material
cartridge on [printer
name] is empty. Please
replace material cartridge
after current job is
completed.
Replace material cartridge
on [printer name] There
is no material in cartridge
on [printer name]. Current
print might not be
completed.
Button: Dismiss
Paused: Low Resin Level
Machine will resume
printing when material
levels rise. Or, the job will
abort after the max pause
time.
Button: Dismiss
No material cartridge
present in [printer name]
Please replace material
cartridge to keep printing.
Button: Dismiss
No material cartridge
present in [printer name]
Please replace material
cartridge to keep printing.
Button: Dismiss
171
STACK LIGHT HOW TO CLEAR
STATE
Flashing yellow This error occurs when the cartridge is
empty, and there is NOT enough material
in the resin tray to perform a build. Insert
a new cartridge of the same material
or perform a Material Changeover before
another job can be sent to the printer.
Solid yellow Insert a new cartridge of the same material
and solid green or perform a Material Changeover after the
current build is complete. There is enough
material in the resin tray to finish the
current build.
Flashing red This will only appear during a print job.
Replace the material cartridge immediately
to avoid a failed build. There is not enough
material in the resin tray to complete the
current build.
Flashing red This will only appear during a print job,
and solid green and will follow error 19, above. Replace the
material cartridge immediately to avoid a
failed build. There is not enough material in
the resin tray to complete the current build.
Solid red This will only appear if you remove a
material cartridge during a build and
do not replace it. Replace the material
cartridge immediately to avoid a failed
build. There is not enough material in the
resin tray to complete the current build.
Flashing yellow
Insert a material cartridge, with material
and solid green
inside, in the MDM to clear this message.
