4. Carefully lower the new resin tray into place, concave side
up, as seen at the right. It should fit snugly in the holder on
the chassis. Ensure that the tray is fully seated and level inside
the chassis.
5. Close the upper-chamber door and push the tension toggle
button. Look at both tension arms and ensure that they are
engaged. If they do not engage, please see the
Hardware
Troubleshooting section
.
6. Close the lower-chamber door and enable the Printer. Ensure that a print platform is installed and, on the Printer, tap the
icon on the touch screen. This will change the unit from "mark as ready" to "ready to print," as in the screens below.
→
3D Systems, Inc.
95
p/n 42-D116, Rev. K
