Fly-out Menu Button - Tap this button to open up the Fly-out Menu from the left side of the screen. Please see the
A
section Fly-Out Menu
Status Tab - Tap this button to go to the Status screen. Please see the section
B
Queue Tab - Tap this button to go to the Queue screen. Please see the section
C
Settings Tab - Tap this button to go to the Settings screen. Please see the section
D
information.
Queue Status - This displays the number of print jobs currently in the print queue.
E

6.1.1 Status Screen

When you power the system on, the touch screen will default to the Status screen. This screen shows the status of each Printer
connected to your Controller. If you leave this screen, you can return by simply tapping the Status Tab near the top of the
screen.
The image below shows the Status screen in Medium view. Please the section
adjusting the size of items on the screen.
3D Systems, Inc.
for more information.
Adjust GUI Appearance
63
Status Screen for more information.
Queue Screen for more information.
Settings Screen for more
for information on
