Printer Message
6.2.1.2 Code Yellow Messages
The following are common Code Yellow Messages and their definitions. This is not a complete list, but is to made to give an
example of each type of Context Button on a Code Yellow screen.
Printer Message
6.2.1.3 Code Red Messages
The following are common Code Red Messages and their definitions. This is not a complete list, but is to made to give an
example of each type of Context Button on a Code Red screen.
Printer Message
3D Systems, Inc.
Definition
This screen appears during a print job. Tap the
button to abort the job at any time.
This screen appears after a print job has completed. When
you are finished switching out the print platform, tap the
button to mark the Printer as ready for a new job.
This screen appears after performing the steps seen in the
screen above. Tap the
button to mark the Printer as "not ready" so that it will not
receive print jobs.
Definition
Screens like this ask the operator to perform a non-critical
action before the Printer can resume normal operation. The
will remain inactive until the task is complete. In this
particular case, install a clean print platform and tap the
checkbox to mark the Printer as "ready."
Screens like this one do not have a Context Button. They
require another action to be taken to, for example, satisfy
a sensor. In this case, the resin-tray sensor does not detect a
resin tray. Insert a resin tray to clear this message.
Definition
Screens like this ask the operator to perform a critical action
to avoid, or recover from, a failure. The
box will be grayed out, and not interactive, until the action is
complete. In this case, you would close the Printer's top door
and tap the checkbox.
