Nylon Printing Best Practices
Introduction
Printing with CubePro Nylon (NYL) is an exciting endeavor for the 3D printing enthusiast.
Nylon is a strong, flexible and durable material. It is an excellent choice for prototyping,
small-run manufacturing and parts requiring secondary operations.
Copyright
©2016 by 3D Systems, Inc. All rights reserved. This document is subject to change without
notice. This document is copyrighted and contains proprietary information that is the
property of 3D Systems, Inc. Cubify, and the 3D Systems logo are registered trademarks of
3D Systems, Inc. CubePro is a trademark of 3D Systems, Inc. Use of the Cubify.com website
constitutes acceptance of its Terms of Service and Privacy Policy.
Compliance
FCC Notice
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
CubePro
Nylon Printing Best
Practices
®
