Front View
Graphical User Interface (GUI) - This is the touch screen that controls all the functions of the Figure 4
A
Modular system. For more information, please see the section User Interface. You can also use the included
Bluetooth keyboard/trackpad to interact with this screen.
Casters - Allow the Controller to move easily throughout a facility. However, the module must be connected
B
to power and Ethernet during operation.
Tray- Use the tray to place the keyboard.
C
USB Hub - There are four USB ports here, to allow for USB drives and other devices to interface with the
D
machine.
