4 FIGURE 4 MODULAR SPECIFICATIONS AND REQUIREMENTS
Total Printer Footprint (xyz)
Doors open
Doors closed
Total Controller Footprint (xyz)
Doors open
Doors closed
Net Build Volume on Print Engine (xyz)
Native Resolution (depending on machine installation)
Projector Wavelength
Material Packaging
Post-Processing
Computer System Requirements
File Input to 3D Sprint
File Export to Controller
Electrical Requirements for Controller
Electrical Requirements for Printer
MAINS supply voltage fluctuations
Overvoltage Category
Circuit Breaker Specifications
Network Ready
Shop Air Requirement
Exhaust Flow Rate

4.1 Properties Figure 4 TOUGH CLEAR

METRIC
Color
Description
Speed (mm/hr) - 30 µm Print Mode/
Standard Build Style
Viscosity (cps @ 25C)
3D Systems, Inc.
61.1 x 155.7 x 209.1 cm (26.0 x 61.3 x 82.3 in)
61.1 x 72.9 x 209.1 cm (26.0 x 28.7 x 82.3 in)
56.5 x 156.3 x 153.8 cm (22.2 x 61.5 x 60.6 in)
56.5 x 65.2 x 153.8 cm (22.2 x 25.7 x 60.6 in)
124.8 x 70.2 x 346 mm (4.9 x 2.8 x 13.6 in)
65 micron (390.8 effective PPI)
405 nm nominal
2.5 kg cartridge
Please see
equipment.
• Windows 7 (SP1),8.1,10 (64-bit only)
• 3D Sprint software (included with Printer)
All 3D model file types
.f4x
100-240 V~, 50/60 Hz., Single Phase, 5 A
100-240 V~, 50/60 Hz., Single Phase, 2.5 A
+ 10%
OVII - energy-consuming equipment to be supplied from
the fixed - installation
connection-technology/approvals-regulatio...
2A, 10A
Built-in Ethernet
70-110 psi of dry air, < 1 cfm consumption
Variable, 82-410 cfm
METHOD
N/A
N/A
Internal Method
Brookfield viscometer
37
Post-Processing Guide for recommended
https://www.ptr.eu/en/know-how/
VALUE
Gray
A clear, production-grade material
engineered to offer long-term
environmental UV, humidity stability,
and clarity that avoids fading or
discoloration for up to 8 years.
Up to 17
41
p/n 42-D116, Rev. K
