5.2.1 Find Modular System on Network

1. Open 3D Sprint.
2. If the Printer dialog box is not already open, click the
icon in the upper-left-hand corner (1).
3. In the Printer dialog box, click the Find Printer button (2).
3D Sprint should find your Controller on the network. If
this does NOT happen, enter your Controller's IP address
in the Find by printer IP field (3) and press Enter. The
Controller's IP address can be found by going to the
Settings tab on the touch screen.
4. Click the Figure 4 Modular icon (4) that comes up. Click
Next (5).
Note: You must make the Controller's IP
address an exception on your network's
firewall.
There are many different materials, material shades, and print
modes to choose from.
1. Click the icon of the print material you will use in your
build. Click Next.
3D Systems, Inc. 56 p/n 42-D116, Rev. K
