# ERROR TEXT ON
PRINTER DISPLAY
26 Job Aborted: Possible
overflow Our
sensors detected a
material overflow or
obstruction. Please
consult the user guide.
3D Systems, Inc.
ERROR TEXT ON
CONTROLLER
Possible resin overflow
detected in [printer
name] Our sensors have
detected a possible
resin overflow or sensor
obstruction. Current job is
being aborted and printer
will remain disabled until
sensors are cleared.
Please refer to the
user guide for cleaning
procedure.
174
STACK LIGHT HOW TO CLEAR
STATE
Flashing red
This message appears if there is a material
overflow detected when the machine IS
printing.
1. Inspect resin tray and upper-build
chamber for overflowing material.
a. If you suspect that the resin tray
is leaking, perform the steps in
the section
Leak
b. If overflow is observed, turn off
the printer. Refer to troubleshooting
item HW4
Cease operation of the printer and
contact 3D Systems Service.
c. If material is not actually
overflowing:
1. Remove resin-tray lid if installed.
2. Inspect the material-level sensor
3. If these steps do not resolve
2. If resin tray has leaked or overflowed,
inspect lower build chamber and both
the Printer Drip Tray and MDM Drip Tray
for material contamination. If material is
contained in the drip trays, clean them
and the spill sensor, according to the
section
3. Tap Overflow Resolved on the Controller
popup:
4. Complete the steps in the section
Aborting
Recover from Resin-Tray
.
to clean the material spill.
and ensure it is clean of material
and that nothing blocks its path
to the top of the material.
Anything in the way of the
sensor could make the sensor
believe the material level is in an
overflow state.
issue, the resin tray is likely
over-filled. Use a syringe or
other material handling tool to
carefully remove material from
the resin tray until the fault is
cleared. Discard the syringe or
tool according to all government
regulations.
Clean Drip Trays .
.
