WEAR GLOVES: Due to the possibility of material being on the RESIN-tray garage, wear 100% nitrile gloves
whenever handling it, even if it appears clean.
3.3.1.1.2 Print Platform
Print platform properly seated in machine
3D Systems, Inc.
Print Surface - Faces downward when printing.
A
The printed part adheres to the holes in the print
surface on the underside of the platform.
Alignment Grooves - The flat surfaces of
B
the platform are held to the elevator arms
magnetically. The triangular grooves fit over the
conical pins on the elevator arms.
QR Code/Serial Number - The QR Code has the
C
serial number embedded in its pattern. These
give the print platform a unique identification
that can be read by a QR-code scanner.
Material Drainage Holes - Prevent material from
settling on the top of the print platform
