SERIAL-PERIPHERAL INTERFACE (SPI)
Table 23. SPI Main Configure Struct Definition (Continued)
Type
adi_adrv9001_spiMasterTriggerSource_e
uint32_t
uint8_t
analog.com
Name
triggerSource
wakeupTimer_us
spiData[SPI_MASTER_TOTAL_BYTES_MAX]
ADRV9001
Description
SPI master transaction trigger source.
Monitor mode for early wakeup timer for
SPI Main transaction. Only available if trig-
gerSource = ADI_ADRV9001_SPI_MASTER_TRIG-
GER_SOURCE_MONITOR.
Bytes to be written to the SPI sub device. By default
populated with zeros. Note: SPI Main makes no distinc-
tion between op-codes, addresses, and data; these are
all treated as one in the spiData array.
